4K wireless digital box installation

Follow the instructions to install your 4K wireless digital box

In order to configure your digital box, you must have a working Internet network.

Learn how to configure a
TELUS Wi-Fi Hub
.

Learn how to configure an
Actiontec T3200 modem
.

To install your 4K wireless digital box, please start with step 2.

To change an existing digital box, please complete the step below first.

  1. Disconnect all cables connected to the existing digital box.
    Install your 4K wireless digital box by following these steps:

  2. Connect the power of your 4K wireless digital box with the cable provided

    Connect the power of your 4K wireless digital box
  3. Using the HDMI cable included in the box, connect the wireless digital box to an unused HDMI socket on your TV

    Connect the wireless digital box to an unused HDMI socket
  4. Using the remote control supplied with your TV, turn on the TV and use the input/source button to select the desired input

  5. When the screen illustrated below appears, press the
    Ok
    button on your OPTIK remote control

    OPTIK remote control
  6. When the screen illustrated below appears, press and hold the WLS button on your modem for 10 seconds. The Wi-Fi indicator will flash to indicate that synchronization is in progress. This may take a few minutes

    Illustrated screen

    4K wireless digital box installation
  7. A message will appear on the screen confirming that the synchronization has been successfully completed. Connection bars appear on your wireless digital box

  8. Please select the language of the PVR. Select
    Menu
    on the remote control >
    Settings
    >
    General
    >
    Display language
    > Choose the preferred language and then
    Save

    Select menu

If synchronization fails, repeat the steps from step 2.

For help, visit
telus.com/selfinstall
.
